Then calibrate the scale with K, drop cameras with C, and trace the walls with W so the coverage knows what it can't see through.
Then calibrate the scale with K, trace the walls with W or B, and place detectors, call points and sounders with C — or tap each room with auto-place (A).
You drew a line 0 px long. What is that on the ground?
A plain number is millimetres · or type a unit: 4.5 m, 450 cm, 4500 mm
Handy references: a UK parking bay is 4,800 × 2,400 mm, a single carriageway lane 3,650 mm, a standard door leaf 900 mm (a doorway about 926 mm), a shipping container 6,058 or 12,192 mm long.
What are you designing? The tools, the library, the checks and every output — PDF, proposal, schedules, link and email — follow the type you pick.
Starting a new design clears the one that is open — save it first if you need it.
You can switch a drawing between CCTV and fire alarm later with the switch in the top bar; anything of the other kind is kept, hidden, until you switch back.
Opens your browser print dialogue — choose Save as PDF for a file, or send it straight to the printer. Set margins to None and turn on background graphics.
An A4 sheet to hang beside the panel: the zones with their names, the plan with each zone coloured and numbered, You are here, and your details. Pick the way round:
Opens your browser print dialogue — choose Save as PDF for a file, or send it straight to the printer. Set margins to None. The zone plan also goes in the full PDF when Zone plan sheet is ticked there.
Creates a private web link that opens this design on any phone or laptop — coverage cones, day and night, tap-a-camera, the schedule.detection, call-point and sound coverage, tap-a-device, the schedule. Anyone with the link can view it. Nobody can edit it.
Loading…
Each time the link is opened: when, IP address, approximate place (from the IP, city level), browser, system and device. Your own “open in designer” is not counted. Kept for 90 days, last 300. Test use for now — a cookie and data notice for viewers goes on the link before this is used with clients.
Set once per browser. The key is the PUBLISH_KEY secret on the Cloudflare Worker — it unlocks publishing, your saved designs and the link manager.
Live. Send this link to the client:
Loading…
Enter the PIN you were given with the link.
| Select / move | V | Place cameraPlace fire device | C |
| Draw wall | W | Draw cable route | R |
| Place recorder or head-endFire device list | NC | Add label | T |
| Calibrate scale | K | Measure | M |
| Pan | H / space-drag / middle-drag | Zoom | wheel |
| Finish a line | Enter / double-click | Cancel | Esc |
| Close a building | click the first corner again — it rings green when you are on it | ||
| BuildingRoom or building (3-click rectangle) | B | Snap to objects on/off | S |
| Circle — tree or round building | G, click the centre, then the edge (or drag) — size shown as Ø; a fixed diameter in Properties plots one per click | ||
| Round / polygon building | B, then Alt-click the centre and click one corner — sides set in Drawing aids | ||
| Door | D | Cycle door swing / hinge | E |
| Door types | single, double, unequal double, roller shutter, sliding single / double — pick before placing (Properties shows the door tool's settings) or change on a selected door | ||
| Tool settings | pick a tool with nothing selected and Properties sets what the next item gets — place many alike · Reset to defaults puts them back | ||
| Favourites | star a device in the library to keep it at the top · while placing, E cycles through your favourites | ||
| Keyboard map | hold Q | or hold the keyboard button, right of the plan | |
| Select many | drag a box on empty space (adds to the selection) · ⌘A or Select all takes everything · the bar under the status pill, top left, sets which kinds — lit chips with a tick are included · Shift-click adds or removes one · ⌘D deselects | ||
| Edit several at once | select them, and Properties shows what they share — zone, location, ceiling and loop for fire deviceslocation, model, height and tilt for cameras; a change goes to all of them as one undo step · Mixed means they differ · Properties also offers to select all of the same type | ||
| Quick edits in Schedules | click a location or zonelocation or cable run name in the table to change it · Enter or Tab moves down, Shift goes up, Esc puts it back | ||
| Type a length while drawing | 4500 (mm) · 4.5 m · 450 cm · 3000@90 (bearing) · Enter | ||
| Line up devices | hold Shift while placing a device (or dragging one) — it goes level with the nearest device, same type first: on its row or column, both at once when near another's, along the wall for a wall device · dashed guides and the distance show where · let go for free placement · on a phone or tablet use the Align chip in Properties, the To place list or the selection bar | ||
| Straight lines | hold Shift while drawing or dragging a corner — the line stays at 0, 45 or 90° and still snaps onto walls, joins corners on the line and stops level with other corners (dashed guide) | ||
| Continue a wall | with the wall tool, click the free end of an existing wall | ||
| Filled shape / blankingShape / detection zone | X | Redo | ⌘Y |
| Drawing type | each design is CCTV or fire alarm — picked under File → New, switched with CCTV / Fire in the top bar. Items of the other kind are kept, hidden, until you switch back | ||
| Cameras | C opens the camera library, N the head-end list · drag the blue dot to aim, round for bearing, in or out for tilt · Night shows each camera's illuminator reach | ||
| Zone plan | Z | Done | Z / Esc |
| Print the zone plan | ⌘P in the zone plan, or Print / PDF in its bar — an A4 sheet to hang beside the panel, portrait or landscape · ⌘E there saves it as a PNG | ||
| Zone plan tools | F fill a room (found from the walls) · R rectangle · P free draw · Y You are here · V edit corners · 1–9 pick a zone · N new zone · Del removes the selected area · tap a coloured room with another zone picked to move it | ||
| Zones of devices | once rooms are coloured on the zone plan, a device takes the zone of the room it is in — a wall device the room it faces, so F moves it to the zone the other side · a short note says the zone when you place or drop one · a zone typed in Properties always wins; clear it to follow the plan again | ||
| Design certificate | Certificate in the top bar, or Export → Fire alarm design certificate — the model certificate filled from the drawing · sign on screen, add up to 10 photos · Print certificate gives it on its own (A4 portrait); tick it in Print / PDF to add it to the PDF | ||
| Sound level reading (as-fitted) | L | click where you measured, type the dB(A), Enter · checked against BS 5839-1 clause 15 — area type and background noise in Properties | |
| Signal levels (as-fitted) | a wireless device's signal in dB, as the Ajax app shows it (red weak ≤16, amber medium 17–22, green strong ≥23), goes in its Properties — or in the Signal column of Schedules → Fire devices, where Enter moves down to the next device · shown on the device's icon on an as-fitted drawing | ||
| Auto-place detectors | A | tap a room — the fewest detectors that reach every point go in at once (a corridor ≤2 m wide by the corridor rule, at any angle) · tap the next room · − / + (keys or the chips by the room) change the last room · tap a filled room again to replace its detectors · ⌘Z takes a room off · Esc or V leaves · detector, roof pitch and the gap hatch in Properties | |
| Fire devices | C opens the device list, click the plan to place (a beam takes two clicks) · a wall device is drawn on the side of the wall it is fixed to, F flips it · shapes with a zone number are detection zones · Shift-click with the door tool for a fire door | ||
| Drawing setup | site, background image, scale, fire alarm settings, the drawing type and the item list live under the Drawing setup button | ||
| Pictures | I (or File → Add a picture), click where it goes and pick the file — or drop / paste an image onto the plan and choose “on top”; size, rotation and layering in Properties | ||
| Edit a wall / shape / route | select it, drag a corner · double-click a side to add a corner · right-click or double-click a corner to remove it | ||
| Delete selection | Del | Deselect · Duplicate | ⌘D · ⌘⇧D |
| Copy / cut selection | ⌘C / ⌘X | Paste at the cursor | ⌘V |
| Nudge / rotate 1° | arrows / , . | Rotate 15° | Shift , . |
| Fit to content | Shift F | Undo / redo | ⌘Z / ⌘⇧Z |
| Paste an image as background | ⌘V | ||
Build . Library figures are indicative and taken from published specifications. Always check the current datasheet before a design goes to a client — lens, sensor format and illuminator distancedetector ratings, sounder output and radio range vary between hardware revisions.
